TCD001 Pressure Switch

Brand: Burkert Fluid Control Systems
Does not ship to United States

The pressure switch is used to convert adjustable pneumatic signals into electrical signals.
Features
  • For neutral gases and liquids
  • Models normally open contact, normally closed contact or changeover contact
  • Switching point can be adjusted with grub screw

Specifications

Burst Pressure

  • psi: 145 to 4,351 (kPa: 1,000 to 30,000, bar: 10 to 300) - AF24
  • psi: 290.1 (kPa: 2,000, bar: 20) - AF19
  • psi: 290.1 to 4,351 (kPa: 2,000 to 30,000, bar: 20 to 300) - Flange Mounting

Diaphragm Material

  • NBR

Electrical Connectors

  • Coupling Socket PG9 (DIN EN 175301-803)

Electrical Contacts

  • Changeover Contact - AF24, Flange Mounting
  • Normally Closed Contact - AF24
  • Normally Open Contact - AF19, AF24

Environmental Protection

  • IP00 - AF19, AF24
  • IP20 - AF19, AF24
  • IP65 - Flange Mounting

Load

  • 2 A, Max.

Materials of Construction

  • Brass
  • Galvanized Steel - AF24, Flange Mounting
  • Stainless Steel - AF24, Flange Mounting

Media

  • Air
  • Hydraulic Oil - AF24, Flange Mounting
  • Oil Emulsion - AF24, Flange Mounting
  • Water - AF24, Flange Mounting

Mounting

  • Flange Mount

Process Temperature

  • -25° to 85° C (-13° to 185° F)

Seat / Seal Material

  • Urethane (UR) - AF 24, Flange Mounting

Set Point - Decreasing

  • bar: 0.3 to 200
  • kPa: 30 to 20,000
  • psi: 4.351 to 2,901

Set Point - Increasing

  • bar: 0.3 to 200
  • kPa: 30 to 20,000
  • psi: 4.351 to 2,901

Switching Maximum

  • Switching Frequency: 200 CPM, Max.

Voltage

  • Reference Voltage: 150 V, Max.
  • Reference Voltage: 42 V, Max.
