Worcester-Controls Sanitary Ball Valve, WK 44
Images are representations only.

WK 44 Sanitary Ball Valve

Brand: Worcester-Controls
Request Information
Favorite

Series WK 44 Clean Valves are operating dependably in processes in the pharmaceutical, biotech, food, cosmetic, paint, chemical and other industries where microbes, media deposits, particle generation and cross-contamination can threaten the quality of the product.

The high-purity design, high vacuum rating, high cycle life and pressure/temperature rating of these valves help assure quality production with minimum downtime. They last many times longer than diaphragm valves and prevent catastrophic failure.

Specifications

Brand

Approvals & Certifications

  • U.V. Light Test
  • Helium Leak Test
  • Wipe Test
  • Compliance
  • CE
  • FDA (21CFR)
  • ISO 9001
  • PED
  • USDA (with TFE or UHMWPE Seats)

Ball Material

  • 316L Stainless Steel - ASTM A479

Bearing Material

  • Thrust Bearing: PEEK (UHMWPE with UHMWPE Seats)
  • Thrust Bearing: Polyfill (UHMWPE with UHMWPE Seats)

Enclosure Finish

  • Interior Surface Finish: Electro-Polishing 30 Ra, 15 Ra
  • Interior Surface Finish: Mechanical Polish 6-10 Ra

Enclosure, Body Material

  • 316L Stainless Steel - ASTM A351 CF3M

Flow Capacity

  • 8 to 36 Cv

Handle Assembly Material

  • Stainless Steel, Plastisol-Dipped Sleeve

Materials of Construction

  • Belleville Washers: AISI 301 Stainless Steel
  • Follower (AISI), Pipe Ends (ASTM A351 CF3M): 316L Stainless Steel
  • Lockwasher (AISI), Stop Pin (ASTM A276): 300 Series Stainless Steel
  • Seal Protector: PEEK

Nut & Bolt Material

  • Body Bolt: 316 Stainless Steel (ASTM F593 Grade 2)
  • Body Nut: Stainless Steel (ASTM A194 Grade 8)
  • Retaining Nuts: AISI 300 Series Stainless Steel (Zinc-Plated)

Operating Pressure

  • One-Piece Seat/Body Seal - psi: 800 (kPa: 5,516, bar: 55.16)

Operation

  • Electrical Operation for ON/OFF
  • Lever Handle
  • Pneumatic Operation for ON/OFF
  • Porting: 180° with Shutoff
  • Porting: 90°
  • Throttling Control

Port

  • Reduced (Standard, Regular)

Seat / Seal Material

  • Body Seal: TFE Coated Stainless Steel ”S” Gasket
  • Seat/Body Seal: TFE-Virgin
  • Seat/Body Seal: TFM
  • Seat/Body Seal: UHMWPE
  • Stem Seal (with TFE or Polyfill Seats), Seat/Body Seal: Polyfill

Stem Material

  • One-Piece, Bottom Entry: 316L Stainless Steel (ASTM A479)

Tube Connection

  • 1” O.D. Tube
  • 1/2” O.D. Tube
  • 1-1/2” O.D. Tube
  • 2” O.D. Tube
  • 3/4” O.D. Tube

Valve Size

  • 1/2” to 2” (12.7 to 50.8 mm)

Valve Type

  • Automated
  • Manual

Welded Connection

  • 1” Butt Weld End
  • 1/2” Butt Weld End
  • 1-1/2” Butt Weld End
  • 2” Butt Weld End
  • 3/4” Butt Weld End

  • Pharmaceutical/Biotech (High-purity Water, Sterile Steam, Flush-bottom Tank Valves, Cleaning: Acids, Caustics, Deionized Water, Gas & Air Sparging, Media & Nutrient Inlets)
  • Microelectronics Manufacturing (High Vacuum, High-purity Gases, Toxic Gases, Solvent Lines, Instrumentation Tie-ins)
  • Paint
  • Chemical Industry
  • Cosmetics & Creams (Oils, Shampoos, Detergents, White Wax)
  • Food Processing (Wine & Spirits, Hot Cooking Oils, Steam, Water Feed Lines, Retort Lines)
  • Lyophilization or Freeze-Drying (High Vacuum, Cryogenic Liquids, Super-cooled Oils, Sterile Steam, High-purity Inert Gases)
  • Sterile Steam & Distillation (Distilled Water, Recirculation Loops)
