8708 Liquid Flow Meter

Brand: Burkert Fluid Control Systems
Does not ship to Virginia, United States

Type 8708 is an instrument for liquid flow control in process technology. The actual value supplied by the sensor is transmitted through the digital electronics and over a standard signal output or a field bus interface.

In the device two calibration curves can be stored, which the user is able to switch between. The device offers a particularly compact solution.

MassFlowCommunicator software can be used for parameterisation and diagnosis.

Specifications

Accuracy

  • ± 0.5 % of Full Scale
  • ± 1.5 % of Reading

Ambient Temperature Range

  • 0° to 55° C (32° to 131° F)

Applications

  • Bio Reactors
  • Fuel Cell Technology
  • Heat Treatment
  • Liquid Level Measurement
  • Machine Tools
  • Material Coatings
  • Packaging Technology

BSP Connection

  • G 1/4” Female
  • G 1/8” Female

Communication

  • DeviceNet Bus
  • Digital
  • FOUNDATION Fieldbus, CAN Open
  • PROFIBUS DP V1

Consumption

  • Power Consumption: 5 W with Fieldbus Version
  • Power Consumption: Max.

Electrical Connectors

  • DeviceNet & CANopen: M12 Plug, 5-Pin
  • D-Sub 15-Pin Connector
  • PROFIBUS: 5-Pin M12, Socket

Electrical Contacts

  • Normally Closed
  • Normally Open

Enclosure, Body Material

  • Polycarbonate
  • Stainless Steel

Environmental Protection

  • Typical of Protection: IP40

Flow Rate

  • Full Scale Range: 0.015 to 0.6 LPM Water
  • Full Scale Range: 0.9 to 36 L/hr

Indication

  • LED Indication Power, Communication (Only in Fieldbus Version), Limit (Only in Analog Version) & Error

Media

  • Clean & Low Viscous Liquids
  • Water

Mounting Position

  • Horizontal
  • Vertical

NPT Connection

  • 1/4” NPT Female
  • 1/8” NPT Female

Operating Pressure

  • Maximum
  • Typical, Max.

Operating Voltages

  • 24 Vdc ± 10 %

Output

  • 0-10 V, Actual Value
  • 0-20 mA (Actual Value)
  • 0-5 V, Actual Value
  • 4-20 mA (Actual Value)
  • Burden (Current Output): 600 ohms, Max.
  • Maximum

Process Temperature

  • 10° to 40° C (50° to 104° F)

Relay Output

  • One Relay Output: 1 A at 25 V, 25 VA

Repeatability

  • ± 0.5 % of Full Scale

Response Time

  • < 500 milliseconds

Seat / Seal Material

  • Seal: EPDM
  • Seal: FFKM
  • Seal: FKM

Sensor Circuit

  • Residual Ripple: < 2 %

Sensor, Probe Type

  • Differential Pressure

Turndown

  • 1:10

Viscosity

  • 0.4 to 4 cSt

  • Heat treatment
  • Machine tools
  • Fuel cell technology
  • Packaging technology
  • Material coating
  • Bio reactors
