Burkert Full Bore Magmeter, 8054/8055
Images are representations only.

562 128

Series: 8054/8055 Full Bore Magmeter Brand: Burkert Fluid Control Systems
Price
Request a Quote
Stock
Out of Stock
Does not ship to OH, United States
Request Information

Burkert Full Bore Magmeter, 8054/8055 Burkert Full Bore Magmeter, 8054/8055

Specifications

Brand

Applications

  • Water Treatment

Approvals & Certifications

  • CE
  • EN 1092-1

Cable Length

  • Remote Version (S055), Electrode Cable, Coil Cable: 10 metres

Conductivity

  • 20 µS/cm Min. with Demineralized Water
  • 5 µS/cm Min.

Diameter

  • Pipe: 1 to 8" (DN 25 to DN 200)

Electrical Connectors

  • 2 Cable Glands PG9
  • Junction Box

Enclosure, Body Material

  • 304 Stainless Steel
  • 316 Stainless Steel
  • Carbon Steel Painted

Environmental Protection

  • IP65
  • IP67
  • IP68

Flange Size - 1-1/2” (DN 40)

  • 1-1/2" (DN 40) - 150# ANSI

Flange Size - 1-1/4” (DN 32)

  • 1-1/4" (DN 32) - 150# ANSI

Flange Size - 1” (DN 25)

  • 1" (DN 25) - 150# ANSI

Flange Size - 2-1/2” (DN 65)

  • 2-1/2" (DN 65) - 150# ANSI

Flange Size - 2” (DN 50)

  • 2" (DN 50) - 150# ANSI

Flange Size - 3” (DN 80)

  • 3" (DN 80) - 150# ANSI

Flange Size - 4” (DN 100)

  • 4" (DN 100) - 150# ANSI

Flange Size - 5” (DN 125)

  • 5" (DN 125) - 150# ANSI

Flange Size - 6” (DN 150)

  • 6" (DN 150) - 150# ANSI

Flange Size - 8” (DN 200)

  • 8" (DN 200) - 150# ANSI

Flow Rate

  • 20,000 gpm (100,000 L/minute, 5,000 m³/hour)
  • Maximum
  • Minimum 0 to 0.4 m/sec: 0 to 45.20 m³/hour

Materials of Construction

  • Electrode: 316L Stainless Steel
  • Electrode: Hastelloy C
  • Electrode: Platinum Rhodium
  • Electrode: Tantalum
  • Electrode: Titanium
  • Lining: Ebonite
  • Lining: Polypropylene (PP) - Max.
  • Lining: PTFE

Measuring Range

  • 0 to 1,130 m³/hour

Pressure Range

  • bar: 0 to 63.98
  • kPa: 0 to 6,398
  • psi: 0 to 928

Process Temperature

  • With PP Lining: 0° to 60° C (32° to 140° F)
  • With PTFE Lining: -20° to 130° C (-4° to 266° F)

Seat / Seal Material

  • Seal: EPDM
  • Seal: FKM
